April 3, 2011

My first professional bug

Filed under: history, programming, Random, Visix — Mark Dalrymple @ 8:23 pm

Clearning with rooking grass

Mike Ash’s recent Friday Q&A about signals mentioned SIGWINCH, the hearing of which always sends me down memory lane.  My first professional bug was centered around SIGWINCH.  By “professional bug”, I mean a bug that someone paid me actual money to fix during a period of employment.

I went to work for a company called Visix straight out of college in the early 90’s, which at the time sold a product called Looking Glass, a file browser much like the Macintosh Finder but for Unix.  Eventually Looking Glass would become the Caldera Linux desktop.  Looking Glass supported the major graphical windowing systems of the time: X11, Intergraph’s Environ V, and Sun’s SunView.  The image at the top of this posting is the only screen shot I could find of the version of Looking Glass I worked on running on SunView.  Notice the awesome desktop widgets at the top.  That was typical SunView style, so Looking Glass was pure awesome eye candy in comparison.

I was hired for the tech support team, and our duties were phone support (typically debugging network configurations and X server font paths) and porting Looking Glass to other platforms.  Being the Lo Mein on the totem pole I got given the old platform nobody wanted to touch any more: SunView.

SunOS 4.1.X had just come out, and Looking Glass would hang randomly.  It worked fine on 4.0.3.  My job was to find and fix this hang.  This was my first introduction to a lot of things: C, unix systems, windowing systems, navigating large code bases, conditional compilation, debuggers, vendor documentation that wasn’t from Apple, working in a company, and so on.  Luckily the SunView version didn’t sell terribly well any more because everyone was moving to X11, but there were a couple of customers bitten by this problem.

So what is SunView?  SunView is a windowing system: different programs run displaying graphical output into a window.  Nowadays that’s commonplace, but back when SunView came out it was pretty cool.  SunView was one of the earlier windowing systems,so it had a bunch of peculiarities: the biggest was that each window on the screen was represented by an honest-to-god kernel device.  /dev/wnd5 is a window, as would be /dev/wnd12.  There were a finite number of these window devices, so once the system ran out of windows you couldn’t open any more.

There was a definite assumption of “one window to one process” in SunView.  Your window was your only playground.  Looking Glass was different because it could open multiple windows.  Because of the finite number of windows available system-wide, we had to create the alert that said “You can’t open any more windows because you’re out of windows” at launch time, thereby consuming a precious window resource, and hide it offscreen.  It was the only way we could reliably tell users why they couldn’t open any more windows.  Glad I wasn’t the one that had to make this work in the first place.  I was just fixing Legacy Code.

The other peculiarity is that you never got window events.  Even in the 1.0 version of the Macintosh toolbox you could easily figure out if the user dragged the window, or resized it, or changed its stacking order.  In SunView you just got a signal. SIGWINCH, for WINdow CHange, and hence the memory-lane trigger.  The user moved a window?  SIGWINCH.  The user resized it?  SIGWINCH.  The user changed the z-order?  SIGWINCH.

With just one window that’s not too bad.  Just query your only window for its current size.  For us, though, we had to cache every window’s location, size, and stacking order.  Upon receipt of a SIGWINCH we would walk all of our windows and compare the new values to the cached version.  If something interesting changed we would need to do the work of laying out the window’s contents.

So, back to my bug.  It took me a solid month to fix.  All this time I thought I was a failure and was worried I’d get fired.  That would be embarrassing. It took so long to fix because it was part time work in amongst my other responsibilities, and also because it was difficult to reproduce.  Spastic clicking and dragging could make it lock up, but not reliably.  Using the debugger was pointless – a 4 meg Sun 3/50 swapped for two hours as dbx tried to load Looking Glass.  I ended up using a lot of caveman debugging.

Event queues

The application event architecture we used is shown right up there.  Each window had an event queue (remember that one window to one process assumption) that held all of the mouse and keyboard events.  Upon receipt of new events (I forget if we got a signal for that, or if some file descriptor became readable), we would walk our windows: read each event, handle it, then move on to the next window.

I was getting some printouts, though, showing an window receiving mouse-downs and mouse-drags, but no mouse-up.  Occasionally I would see a mouse-up, with no mouse-downs.  Ah-ha!  The mouse-up was being delivered to the wrong window’s event queue, probably due to some race condition down in the system that didn’t notice the current window changed during the drag. The fix was easy once I found it : just merge the events from all the windows first, and then process them.  Happiness and light.

It was then I learned how expensive malloc is.  I malloc’d and free’d event structures, but performance was dog-slow, especially during mouse drags.  Caching the structures made life fast again.

Memories like these make me so happy with the cool tech we get to play with these days.

About these ads

7 Comments »

  1. Glad to finally hear the full story of the “bug from hell” of yore. Good times!

    Comment by Dan Gilliam — April 6, 2011 @ 2:17 pm

  2. You may be interested in this post which explorer Looking Glass on both Caldera and Interactive Unix: http://virtuallyfun.superglobalmegacorp.com/?p=2987

    Comment by Antoni Sawicki — March 27, 2013 @ 4:10 am

    • Nice! thank you!

      Comment by Mark Dalrymple — March 27, 2013 @ 9:09 am

      • Would you be able to comment little bit more on different platforms and operating systems that Looking Glass worked on? I only knew one – Kodak/ISC/SunSoft Iteractive UNIX – but no one else, including yourself is mentioning it anywhere. Caldera that’s second and you also mentioned Intergraph. Was there any more? Can you put some history in to it? Thanks!

        Comment by Antoni Sawicki — March 27, 2013 @ 4:12 pm

  3. Sure thing! These are the ones that I can remember off the top of my head

    Windowing systems: SunView (SunOS), EnvironV (Intergraph), X11

    Operating Systems / manufacturers: SunOS (4.X Family), Solaris, CLIX (Intergraph), Stardent/Kubota, Data General, HP/UX, AIX, MIPS (had to run 3-phase power for one of these that became one of our main servers), Sequent, Pyramid, NCR, Apollo Domain, Evans and Sutherland, IRIX/SGI

    Processors: 68K, Sparc, Clipper, Alpha, x86, M88K, RS/6000, ROMP (PC/RT), MIPS, MicroVAX

    Look and Feels: OS/2(ish), Motif, OpenLook

    The place was a candy store of some of the hottest unix machines of the time.

    Comment by Mark Dalrymple — March 27, 2013 @ 4:29 pm

  4. Thanks a lot! WOW it really must have been a candy shop. Do you happen to have some pictures or screenshots from different platforms? Do you know who may have? To my shock you still have not mentioned Interactive UNIX from Kodak/ISC/SunSoft. Was it that insignificant? :)

    Comment by Antoni Sawicki — March 29, 2013 @ 12:51 am

  5. Hey I have found scanned and OCRed couple of Looking Glass documents for Interactive Unix. Release notes and User’s Guide

    http://www.tenox.tc/docs/interactive_unix_sysv386_r32_looking_glass_pro_users_guide.pdf

    http://www.tenox.tc/docs/interactive_unix_sysv386_r32_looking_glass_pro_release_notes.pdf

    Comment by Antoni Sawicki — June 13, 2013 @ 11:57 pm
